– 29 –
Installation and operation
In order to mount the alarm on the ceiling,
follow the steps in the order listed below:
1. Remove smoke alarm from the cover base
by turning anti-clockwise.
2. Remove the locking pin located in the
mounting socket (further use in step 7,
is used for unintentional disassembly).
3. Mark the holes through the cover base.
4. Fit the required rawlplug into the drill hole
and tightly screw in the detector base.
When marking out your drill holes, ensure that no electrical wires
cables, pipes or other installation components are located behind
the installation point!
5. Then enter the current date (installation date)
on the label on the reverse side of the alarm
with a water and abrasion resistant pen
(see illustration opposite).
6. Attach smoke alarm by turning clockwise at the
detector base. Small markings are found on the
side of the detector base and on the alarm itself
which make it easier to fit the alarm onto the base.
7. Insert the locking pin from step 2 into the designated side opening
to prevent the alarm from turning (see next illustration).
Installation and operation
2.
2.
Installationsdatum | Installation date | Date
d'installation: _____________ (DDMMYYYY)
z. B. : 09|05|2016
GB
