Abus RWM450 - Common Radio Group Structure and Activation; Activating the Common Radio Group

– 47 –
Ground Floor Radio Group
max. 15 units
1st Floor Radio Group
max. 15 units
2nd Floor Radio Group
max. 15 units
3rd Floor Radio Group
max. 15 units
The Radio Group as Common
Radio Group
max. 14 radio groups possible
plus CRG stairway
Activate the group you wish to be the
common radio group (e.g. in stairway):
1. Press black activation pin into marked
opening of one of the Stairway group
alarms and hold until LED lights
yellow; continue to hold until LED
blinks yellow.
2. Pull activation pin back, then, for
all alarms added to the radio group
thus far:
 
10 minutes
1. On the next alarm to the stairway
from the Ground Floor radio group,
press the black activation pin:
LED
Signal: short yellow pulse
  
Meaning: Testing in progress,
please wait!
1 second
Radio Group EG
Network setum
