Abus SHHA10000 - Technical Specifications

14
English
4. Technical Specifications
Parameters Unit SHHA10000
Dimensions mm 45 x 45 x 70
Weight g 65
Operating Temperature °C 0 – 25
Max. Humidity % 90
IP Class 20
Radio frequency MHz 868,42 (Z-Wave PLUS, Europe)
Material ABS, polished
Power Supply 220 – 240 V
Power consumption W 1
Measuring range / tolerance V 220 – 240 / 1
Measuring range / tolerance A < 10A / 0,1
Measuring range / tolerance W < 2300W / 1
Maximum Load 2300W (10A/240VAC)
Max. Range (open field) m 100
Max. Range (Building) m 20, related to material of walls
Tamper protection No
Firmware updateable Yes
Support Z-Wave Beaming Yes
SmartStart supported No
Z-Wave Network Security Yes
Z-Wave AES-128 Security No
Z-Wave Plus Yes
Security S2 Classes Yes
Z-Wave Chip Generation 500
Z-Wave Sensor-Typ Enhanced 232 slave
Zwave library type On/off power switch /
Always on slave
