4.4. Reset (Factory-Reset)
1. Press the Tamper-button 3 times within 1.5
Seconds
2. The device is now restored to factory
settings
Note:
1, This procedure should only be used if the
primary gateway is not capable of acting.
2, If the multi-sensor is set to the factory
setting, the status is set to "not included", the
association settings and possible
configurations are reset to default.
5. Advanced Z-Wave Parameter
5.1. Association Group Information
Z-Wave devices can control other devices directly. This direct control is called in Z-
Wave association. For this purpose, the device ID of the device to be controlled must
be stored in the controlling devices. This is done in so-called association groups. An
association group is always linked to an event in the controlling device (pressing a key
or triggering a sensor). When this event occurs, a control command - usually a BASIC
SET - is sent to all devices stored in an association group.
The magnetic contact supports the following association group:
Group
Number
Maximum
Devices
Transmitted Content
Group 1
0x05
Lifeline association group Include command classe:
Battery report, Notification report, and Device Reset Locally
notification, Binary report.
Group 2
0x05
Root Device group(Binary Sensor) Binary Sensor
Command Class:Compatible with 300 series 1-Binary
Sensor reports status of open or close door via Lifeline. 2-
When the sensor detects status change between close
door and open door, the device will be triggered.
Group 3
0x05
Root Device group(Binary Sensor) Binary Sensor
Command Class:Compatible with 300 series
1-Binary Sensor reports the removed status of door sensor.
2-When the sensor detects status change of tamper, the
device will be triggered.
Group 4
0x05
Root Device group(Notification)
1-Notification report open door or close status via Lifeline.
