Abus SHMK10000 - Unterstützte Command Classes; 6 Technical Specifications

11
English
2- When the sensor detects status change between close
door and open door, the device will be triggered.
Group 5
0x05
Root Device group(Notification)
1-Binary Sensor reports the removed status of door sensor.
2- When the sensor detects status change of tamper, the
device will be triggered.
5.2. Supported Command Classes
1 Z-Wave plus Info Version 2
2 Notification Version 8
3 Association Version 2
4 Association Group Info Version 1
5 Transport Service Version 2
6 Version Version 3
7 Manufacturer Specific Version 2
8 Device Reset Locally Version 1
9 Powerlevel Version 1
10 Battery Version 1
11 Security 2 Version 1
12 Supervision Version 1
13 Wake Up Version 2
6. Technical Specifications
Parameters
Unit
SHMK10000
Dimensions
mm
72 x 21 x 26 (Sensor) / 35 x 11 x 13 (Magnet)
Weight
g
45
Operating Temperature
°C
0 – 40
Max. Humidity
%
95
IP Class
20
Radio frequency
MHz
868,42 (Z-Wave PLUS, Europe)
Modulation
FSK/GFSK
Transmission power
db
< 4,5
Power supply
3 V DC
Battery type
CR2
Power consumption standby
mA
0,005
Power consumption trigger
mA
38
Battery-life
3 Years (10 triggers per day)
Range (open field)
m
100
Range (building)
m
20, related to material of walls
Tamper protection
Yes
Firmware updateable
No
Support Z-Wave Beaming
No
SmartStart supported
No
Z-Wave Network Security
Yes
Z-Wave AES-128 Security
Yes
Z-Wave Plus
Yes
