38
English
14. Technical data
Type number TVAC10000
Monitor type Standard TFT LCD
Screen diagonal 8,4“
Resolution 800 (H) x 600 (V) SXGA
Dot pitch (H x V) 0,213 (H) x 0,213 (V) mm
Picture format 4:3
Video system PAL / NTSC
Comb filter 3D
Signal detection Automatic
Contrast ratio 600:1
Brightness 250 cd/m
Color levels 16.2 million
Viewing angle horiz. / vert. 150° (H) x 130° (V)
Response time 16 ms
Frequency range 31.5-80KHz (H) / 56-75Hz (V)
OSD menu Graphical On-Screen-Display
OSD languages German, English, French, Dutch, Danish
Inputs 1x VGA, 2x BNC, 1x S-Video, 2x Audio (3,5 mm phone jack)
Outputs 2x BNC
Loudspeakers Integrated 2 x 1W
Housing material Metall frame
Display matt
Power supply 12 V DC / 5A
Power consumption 11,5 W
Operating temperature -10 – +50°C
Humidity Max 85%
Dimensions (WxHxD) 210 x 190 x 42 mm
Weight 1,3 kg
