32
English
SCENE SELECT
The following setting options are described for the “CUSTOM” option. This option contains all the functions
in the SCENE SELECT submenu.
For the other options (FULL AUTO, INDOOR, OUTDOOR, BACKLIGHT, ITS), sub-functions are either
enabled or disabled by default.
ADVANCEC MENU
PAGE 1 / 2
SHUTTER/AGC AUTO↓
WHITE BAL ATW↓
HLC/BLC OFF
WDR/ATR-EX WDR↓
DNR ↓
DAY/NIGHT AUTO↓
IR OPTIMIZER OFF
RETURN
ADVANCED MENU
PAGE 2 / 2
LENS SHD COMP OFF
DEFOG OFF
FLK LESS OFF
ANTI CR OFF
RETURN
Page 1 / 2
Function Description
SHUTTER/AGC These settings control the exposure of the camera images.
AUTO:
AE LEVEL (1-250): Setting for target automatic exposure
value (basic brightness).
AGC MAX (6-44.8 dB): Setting for maximum gain value
SENSE UP (OFF, AUTO): AUTO: Automatic extension of
exposure time for a brighter picture
OFF: Function inactive
MANUAL: Manual exposure time setting
SHUTTER (x256-x2, 1/50-1/10000): Exposure time setting
AGC MAX (6-44.8 dB): Setting for maximum gain value
FIX: Fix exposure time at current point in time
WHITE BAL This function executes white balance for a realistic colour image.
ATW: Auto tracking white balance – automatic regulation from
1800-10500 K.
SPEED (0-255): Control speed
DELAY CNT (1-255): Delay before control
ATW FRAME (1-255): Calculation interval
ENVIRONMENT (INDOOR, SUNNY, SHADE, AUTO):
Preset for adapting to ambient light
PUSH: Continuous white balance without restriction of colour
temperature. Very intensive colours in the video image can
affect the result.
USER1/2: Manual, user-defined setting of the blue and red values.
Two different sets can be set up.
B-GAIN (0-255): Blue gain value
R-GAIN (0-255): Red gain value
MANUAL: Sets the white balance based on the black body curve,
adjustable in 64 steps.
LEVEL (0-63): Level setting in 64 steps
To Next Page
