33
English
PUSH LOCK: Executes the white balance as PUSH and uses these
values constantly.
HLC/BLC OFF: Function deactivated
HLC: Highlight compensation – an area is marked black above a
certain brightness. This means edges around objects are much
clearer.
BLC: Backlight compensation – dark areas are brightened while
attempting to maintain the brightness of light areas.
WDR/ATR-EX Functions for compensating for high contrast
OFF: Function deactivated
ATR-EX: Software calculation of the WDR function
CONTRAST (LOW, MID, HIGH): Contrast setting
LOW: Low
MID: Medium
HIGH: High
CLEAR FACE (OFF, LOW, MID, HIGH):
Gain function for high-frequency image
sections
WDR: WDR function with double image exposure
CONTRAST (LOW, MID, HIGH): Contrast setting
LOW: Low
MID: Medium
HIGH: High
CLEAR FACE (OFF, LOW, MID, HIGH):
Gain function for high-frequency image
sections
DNR Function to reduce image noise
LEVEL (0-6): The higher the value, the less image noise.
DAY/NIGHT Settings for day/night switching.
AUTO: Automatic switching to night mode
BURST (OFF, ON): OFF: Black/white display in night mode
ON: Colour display in night mode
CNTL SIGNAL (INT, EXT1, EXT2):
INT: Switching based on image
brightness
EXT1: Switching by an external signal at
the D/N input (inverted)
EXT2: Switching by an external signal at
the D/N input
DELAY CNT (0-255): Delay for switching
DAY->NIGHT: Switching threshold from day to night
NIGHT->DAY: Switching threshold from night to day
DAY: Camera remains fixed in day mode
NIGHT: Camera remains fixed in night mode
BURST (OFF, ON): OFF: Black/white display in night mode
ON: Colour display in night mode
IR OPTIMIZER Function to improve the image quality in night mode when using external
IR floodlights
OFF: Function deactivated
ON: Function activated
MODE (AUTO, CENTER): Reference area for calculation
