34
English
AUTO: Automatic
CENTER: Middle area
IR AREA: TOP (0-6): Upper edge of area
BOTTOM (0-6): Lower edge of area
LEFT (0-8): Left limit
RIGHT (0-8): Right limit
WEIGHT (0-15): Weighting
LEVEL (0-12): Degree of improvement The higher the value, the more
the camera tries to improve the image
IR LED:
OFF: Off
FIX: Fixed intensity level
LEVEL (0-255): Level selection
DAY/NIGHT: Reference for IR light intensity is the auto exposure
setting
LEVEL MIN (1-255): Minimum intensity
LEVEL MAX (1-255): Maximum intensity
COLOR NIGHT: Colour display in night mode
OFF: Function deactivated
ON: Function activated
COLOR GAIN (LOW, MID, HIGH): Colour gain
LOW: Low
MID: Medium
HIGH: High
IR SHADE COMP: Compensation for irregular IR illumination in the
video image (corners are darker than the middle of
the image)
OFF: Function deactivated
ON: Function activated
PATTERN (SET1, SET2, SET3):
Illumination pattern selection
POSH (0-959): Horizontal position
POSV (0-578): Vertical position
LEVEL (OFF, LOW, MID, HIGH):
Function levels: Off, Low, Medium, High
RETURN Back to the previous menu page
Page 2 / 2
Function Description
LENS SHD COMP Compensation for irregular IR illumination in the video image (corners
are darker than the middle of the image)
OFF: Function deactivated
ON: Function activated
DEFOG Function to reduce for effects in the video image
OFF: Function deactivated
ON: Function activated
LEVEL (LOW, MID, HIGH): Function levels Low, Medium, High
FLK LESS Function to prevent flicker
OFF: Function deactivated
ON: Function activated
MODE:
GAIN CTRL:
SHUTTER FIX: Fixed exposure time
