36
English
ON: Mosaic view of the area activated
RETURN Back to the previous menu page
MOTION DET
Function Description
MOTION DET Settings for the motion detection function. The alarm output is activated
when a change in the image is detected.
OFF Function deactivated
ON: Function activated
DETECT SENSE (0-127): Sensitivity setting for motion detection
INTERVAL (0-127): Detection interval. A higher value increases the time until the
next detectable event
BLOCK DISP OFF: Live display of image changes deactivated
ON: Live display of image changes activated (block view of the
detected area)
MASK AREA (1-96): A blue marking means the motion detection area is activated.
MONITOR AREA AREA SEL (1-4): Selection of the motion area for configuration
AREA MODE (OFF, ON):
OFF: Motion area deactivated
ON: Motion area activated
TOP (0-15): Setting for the upper limit of the area
BOTTOM (0-15): Setting for the lower limit of the area
LEFT (0-15): Setting for the left limit of the area
RIGHT (0-15): Setting for the right limit of the area
RETURN Back to the previous menu page
SYS MODE
Function Description
SYNC MODE Image synchronisation settings
INT: Internal synchronisation
LL: When using a 24 V AC power supply, LINE LOCK (LL) can be used.
LENS AUTO: Automatic detection of lens type
TYPE (DC, VIDEO): Manual selection between voltage-
controlled (DC) or video signal-
controlled lens type
MODE (AUTO, OPEN, CLOSE): Iris setting
AUTO: Automatic mode
OPEN: Iris fully open
CLOSE: Iris closed
ADJUST: Auto iris calibration
SPEED (0-255): Iris control speed
MANUAL: Manual iris setting
FLIP Image mirroring function
OFF: Function deactivated
V: Vertical image mirroring
H: Horizontal image mirroring
HV: Horizontal and vertical image mirroring
