Abus wAppLoxx Pro Series User Manual

[11] wAppLoxx Pro oval – installation instructions
Installing the outer cap
Screw the outer cap (1) back on by securing the
mounting plate (4) using the opening key (e).
There is a marking on the outer cap (1) that makes it
easier to position the outer cap correctly on the groove
of the knob (3).
When installing the outer cap, it is essential to ensure
that the orange O-ring lies flush between the mounting
plate (4) and the knob (3).

Abus wAppLoxx Pro Series Specifications

General

Brand	Abus
Model	wAppLoxx Pro Series
Category	Door locks
Language	English
