2. Specifications
Angled screen: 143 x 87 x 259 mm
Active scan window (W x D)
Operating temperature: 0ºC to 50ºC
Storage temperature: 0ºC to 60ºC
Humidity: 0–95% RH, non-condensing
Robust PC/ABS enclosure with no moving parts
Display: Colour LCD (480 x 272 px)
Visible/audible: Configurable green (good read) and red (bad read)
indicator beacons and audio beeper
Input voltage: 12 V DC; power adapter supplied
Host interfaces: RS232C (baud rates 9600, 19200, 38400, 115200),
Ethernet*, USB
Host interface for RFID/OCR options: USB only
Serial port: For receipt printers, including the RP9000 or
self-boarding gate applications
1 x mini HDMI*, 3 x USB ports*
Compliance: Supports all necessary AEA2012 symbologies:
1D symbologies: Code 128, Code 2 of 5, Interleaved 2 of 5, IATA 2
of 5, Code 39, EAN
2D symbologies: IATA resolution 792, QR, Aztec, PDF417 and
Datamatrix codes
Performance: Less than 1 second read capability
Will read smartphone, tablet and smartwatch displays, paper
documents and tickets
AirIT Ease®
Amadeus ACUS® (Pending)
ARINC & iMuse®
Edge CUPPS-T (Pending)
RESA CREWS® (Pending)
SABRE EGR®
SITA Airport Connect®
Ultra CUSE® (Pending)
Standard OCR fonts: OCR-B
Machine readable passports (MRP): 2 lines of 44 characters
Machine readable visas (MRV): 2 lines of 44 characters, 2 lines of
36 characters
Travel documents: 2 lines of 36 characters, 3 lines of 30 characters
Contactless RFID reading
(optional)
Supported media: ISO14443 type A and B cards (Java cards); max
baud 424K (extendable to 848K)
Mifare UL, Classic 1K, Classic 4K, Mifare Plus; max baud 106K
Operating frequency: 13.56 MHz
Operating distance: 20 mm
