Access LORADO - Storage and Parts Identification; Strap Adjustment; Parts Diagram

8 9
Premium
storage straps
Front bar
XT-DIAL
TM
tension adjuster
Front
ELEMENT
SEAL
TM
Rail clamps
6–most short boxes
8–long boxes
Left side rail
Rear seal
AUTOLATCH
TM
II dual locking
system on rear bar
Right side rail
Rear bar
Support
bows
To tighten storage strap, pull back on
top layer of strap loop until strap is snug.
To take out slack in loop, slide slip
bracket down.
STRAP ADJUSTMENT
PARTS DIAGRAM
