4
A. Set rolled up cover on rails at front
of box (behind cab) with bar facing up.
Roll cover bar onto front of rails and
fold/tuck vinyl ap under. Now bar will
face down. Let straps hang to inside of
box. Push cover bar forward until it sets
at on front of side rails and overhangs
them.
3. MOUNTING COVER TO SIDE RAILS
B. Slide left tension adjuster over until
it engages under side rail. (See photo in
Step 3 E for tension adjuster tab under
side rail.) Push bar back and forth to line
up holes-do not turn dial wheel. Insert
bolt from top and nut from bottom.
C. Hold bolt at top and tighten nut
under side rail. Repeat procedure for
right hand tension adjuster.
D. Center the front bar between the two
side rails.
E. Then tighten bolt (left loose earlier)
under front bar on each tension adjuster.
Center front bar between
rails until space is equal
at both ends
Tab goes
under–then
tighten bolt
To Next Page
