AccuEnergy EV300 Series User Manual

EV/DV300 Series Power Meter
Appendix
V:2.0 Revised October 2018
53
Analog output (AO)
Output Range
4~20mA or 0~1mA or 0~5V
Resolution
12bit
Max Load
4~20mA
Max load resistance: 500Ω
0~1mA
Max load resistance: 10kΩ
0~5V
Max load current: 20mA
24Vdc power supply (PO)
Voltage Output range
24V(±10%)
Power Rating
2W
Isolate Voltage
1000Vdc
Standard
Measuring
IEC 61036 Class1
ANSI C12.16 Class10
Environmental
IEC 60068-2
Safety
IEC 61010
EMC
IEC 61000-4/2-3-4-5-6-8-11
Dimension
DIN 43700
24Vdc power supply (PO)
Dimension (mm)
96×96×60 (Cut OUT 92×92)
Protection
IP54 (Front), IP20 (Cover)
Weight (g)
500g
Temperature
-25℃~+70℃
Humidity
0~95% Non-condensing
Power Supply
85~264Vac or 100V~280Vdc
Power Consumption
2.5W
