SMART PIPETTE - USER GUIDE
For correct re-assembly, it is crucial that the slots on the tip ejector closer match
the notches on the inside of the main handle. Please follow the above procedure.
Align the notch on the tip ejector with the slots on tip
ejector closer as indicated
1
Ensure the notch on the main handle matches the
slots on the tip ejector closer. Push the tip ejector
closer upwards as indicated.
2
Insert both parts in the aligned manner as indicated.
3
Once completely closed, twist the tip ejector closer in
the indicated direction to close
4
