Northern Hemispheres
Southern Hemispheres
Figure 14
Southern Hemispheres (SOU)
For Southern Hemisphere installations, ignore these (N, S, E, W) and face the solar panel to the North (and
in a sunny position) when it comes to installing the Integrated outdoor transmitter.
Step 1: Install the Integrated outdoor transmitter and face the solar panel North.
Step 2: Set the Console operation to Southern Hemispheres (SOU in the time area) in Location division.
Note: Permanent wind direction error of approximately 180º will occur if the wind direction sensor is not
positioned correctly during installation.
Attach the integrated transmitter to mounting pole brackets, with two ￠3 bolts and M3 nuts, as shown in
Figure 15.
