Installation & Operation Manual - Model AVT4000
Contents of this Manual are Subject to Change Without Notification Page 6
SECTION 2 - SPECIFICATIONS
+/- 5% of reading or 5 CFM, whichever is greater
< 1 second control signal response (full stroke cycle time is 10 seconds)
Standard: < 1.5% FS @ max operating pressure
“S” Option: < 0.5% FS round valves, < 1% FS rectangular valves @ max operating pressure
3”wc Differential Pressure Across Valve
Airstream: -20 to 165 deg. F for all Standard Valve Models
Ambient: -20 to 125 deg. F
Storage: -40 to 165 deg. F
24 VAC +/- 20% 50/60 Hz, 6 VA max
0-20mA, 4-20mA, 0-10V, 2-10V, 0-5V, or 1-5V (Software Config.)
Capable of driving 1K-ohm load
USB Type C Connector, Wireless Bluetooth (Optional)
EIA 485 2-wire BACnet MS/TP, Galvanically Isolated
Data Rates 9600, 19200, 38400, 57600, 76800 and 115200
1/8 Unit Load Receiver Input Impedance
3-position, vertical pluggable, screw on top, wire size 12-30 AWG
Electromagnetic
Compatibility
2014/30/EU, EMC Directive
EN61236-1:2013
2014/53/EJ, Radio Equipment Directive
EN301489-1, V1.9.2:2011
ETSI EN301489-1, V2.2.0:2017
ETSI EN301489-3, V1.6.1:2013/V2.1.1:2017
ETSI EN301489-17, V2.2.1:2012/V3.2.0:2017
2014/35/EU, Low Voltage Directive
EN61010-1:2010/A1:2019/AC:2019
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct
the interference at the user’s own expense. This Class A digital apparatus meets all
requirements of the Canadian Interference-Causing Equipment Regulations.
Units provided with the optional Bluetooth low energy module contain
FCC ID: XPYNINAB1
IC: 8595A-NINAB1
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions;
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.
