12
Stack Cutting (Figure 14)
Stack cutting may be used when several identical
shapes need to be cut.
Several workpieces (2) may be stacked one on
top of the other and secured to each other
before cutting.
Pieces of wood may be joined together by placing
double sided tape (1) between each piece or by
wrapping tape around the corners or ends of the
stacked wood.
The stacked pieces must be attached to each
other in such a way that they can be handled on
the table as a single workpiece.
WARNING: To avoid serious personal injury, do not cut several workpieces at a time unless
they are properly attached to each other.
WARNING: Do not let familiarity with the saw create carelessness. Remember that a careless
decision made quickly can create a serious injury.
WARNING: RISK OF PERSONAL INJURY. Always disconnect tool from power source before
making any adjustments, installing or changing accessories.
CAUTION: Tool service must be preformed only by qualified repair personnel. Service or
maintenance performed by unqualified personnel could result in a risk of injury. When servicing
a tool, use only identical replacement parts. Follow instructions in the Maintenance section of
this manual. Use of unauthorized parts or failure to follow Maintenance Instructions may create
a risk of electrical shock or injury.
General Maintenance
1. Clean the housing, table, base and motor vents after each use.
2. Lubricate moving parts with light weight oil.
3. Apply a thin coat of hydrophobic grease to table so that the workpiece slides easily
while cutting.
4. Store the tool on a safe and dry place, and out of reach of children.
5. If tool begins to make abnormal noise, vibrations, produces smoke or burning odor, turn the tool
off immediately and do not operate, until repaired.
6. Keep tools sharp and clean for best and safest performance. Follow instructions for lubricating
and changing accessories.
7. Do not allow any build up of resins or sap on the saw table. Clean with gum and pitch remover
as needed.
WARNING: When replacing parts, use only identical replacement parts. The use of any other
part may create a hazard or damage the saw.
MAINTENANCE
Figure 14
1
1
2
3
WARNING! For Your Own Safety Read Instruction Manual before Operating Saw
1. DO NOT OPERATE scroll saw until it has been assembled and installed according to the
assembly instructions.
2. ALWAYS wear eye protection.
3. ALWAYS clamp or bolt scroll saw to workbench or table before use.
4. DISCONNECT the power cord and wait for the blade to come to a complete stop before making
any adjustments or changing blade.
5. BE SURE all adjustments knobs, screws or levers are tight and secure before use.
6. KEEP ARMS, HANDS AND FINGERS away from the blade and blade guard (drop foot)
during use.
7. NEVER use damaged or dull blades.
8. ALWAYS use appropriate speed for material and cutting tool being used.
9. ALWAYS support long workpieces to prevent the cutting tool from binding.
10.DO NOT operate scroll saw with guard or covers removed or modified. Make sure guards are in
place and working properly before use.
11.ALWAYS adjust the blade guard (drop foot) so that it rests on the workpiece.
12.NEVER cut through nails.
13.DO NOT cut work pieces that are too small to hold safely.
14.MAKE SURE table is clear of tools, marking equipment or other debris before operation.
15.NEVER start saw when blade is in contact with workpiece.
16.NEVER leave tool unattended while running. Turn power off and do not leave the tool until the
blade has come to a complete stop.
17.ALWAYS allow the motor to reach full speed before starting a cut to avoid the blade from
jamming or binding.
18.NEVER feed workpiece too quickly. Do not force the workpiece against the blade.
19.ALWAYS maintain good balance and avoid awkward operations and hand positions.
20.NEVER remove jammed or scrape pieces of material until the blade has completely stopped.
21.NEVER attempt to adjust or touch the blade tension knob or blade guard (drop foot) when the
saw is on or the blade is moving.
SPECIFIC SAFETY RULES FOR SCROLL SAW
CALIFORNIA PROPOSITION 65
WARNING: CHEMICAL HAZARD. Use of this tool may cause exposure to chemicals that are
known to the state of California to cause cancer, birth defects or other reproductive harm. Dust
and debris created during cutting, drilling, grinding or sanding on some materials may contain
chemicals known to the State of California to cause cancer or birth defects or other
reproductive harm. Some examples of these chemicals are:
• Lead from lead-based paints
• Crystalline Silica from bricks and cement and other masonry products
• Arsenic and Chromium from chemically- treated lumber.
To reduce exposure to these chemicals, always use approved safety equipment, work in a
well-ventilated area and wear dusk mask that filters out microscopic particles.
