7
English
Bottom view
# Item Description
1 Battery bay Houses the computer's battery pack.
2 Battery lock Locks the battery in place.
3 Cooling fan Helps keep the computer cool.
Note: Do not cover or obstruct the
opening of the fan.
4 Ventilation slots Enable the computer to stay cool.
5 Memory compartment Houses the computer's main memory.
6 Battery release latch Unlatches the battery to remove the
battery pack.
