Chapter 3 63
7. For Aspire 8530 Series, move the antenna away from the WLAN board and remove the two screws (B) on
the WLAN board to release the WLAN board.
8. Detach the WLAN board from the WLAN socket.
Step Size (Quantity) Color Torque
1~2 M2 x L4 (2) Silver 1.6 kgf-cm
