92 Chapter 3
22. Remove the thirteen screws (A) from the bottom panel.
23. Turn the unit over and remove the three screws (A) from the top panel.
Step Size (Quantity) Color Torque
1~13 M2.5 x L8 (13) Black 3.0 kgf-cm
Step Size (Quantity) Color Torque
1~3 M2.5 x L8 (3) Black 3.0 kgf-cm
To Next Page
