Chapter 3 Technical Information
Specifications
LCD Panel
Size 17" (43 cm)
Display Type Active matrix color TFT LCD
Resolution 1280 x 1024
Display Dot 1280 x (RGB) x 1024
Display Area (mm)(H x V) 337.92 x 270.336
Display Color 262K
Brightness 250 cd/m
2
(typical), 200 cd/m
2
(minimum)
Contrast Ratio 430:1 (typical)
Response Time Ta=25°C Tr+ Tf=20ms
Lamp Voltage 700 Vrms (typical)
Lamp Current 6.5 mA rms. (typical)
Viewing Angle Vertical: -65° ~ +65°
Horizontal: -80° ~ +80°
Display Colors
16.7M with FRC or Dithering
Video
Input Signal
Input Impedance
Polarity
Amplitude
Multi-mode Supported
Analogue RGB 0.7Vp-p
75 Ohm ± 2%
Positive, Negative
0 - 0.7 ± 0.05 Vp
Horizontal Frequency: 24 ~ 80 KHz
Vertical Frequency: 49 ~ 75 Hz
Control
Power switch On/Off switch with LED indicator
Audio (AL1715 m/AL1715 bm)
Input 500mVrms
Output 1W+1W
OSD
Brightness
Contrast
Horizontal Position
Vertical Position
Phase
Clock
Display Mode Setup
Digital
Digital
Digital
Digital
Digital
Digital
Use EEPROM to save settings in memory
