39
Put the screws on EMI cover with monitor.
1. Connect the back cover with monitor.
2. Firmly secure the back cover with 4 screws.
1. Assemble the neck bracket onto neck.
2. Firmly secure the neck bracket with 4 screws.
1. Connect the hinge with neck.
2. Firmly secure the hinge with 3 screws.
1. Assemble the neck with back cover.
2. Firmly secure the neck with 4 screws.
Assemble the base with monitor
