Part list
A. For AL1715
No. Photo Part Name Description Vendor No.
1
Back Cover Screws M4X0.7+6P-NI MAA20093004
2
BaseASSY(FOOT) AR7714A(ABS94HB,MCG62) FAAR7714A10
3
Stand Screws
M4X0.7+11P-MC
WASHER DIM 8.0
MAA70002400
4
NECK COVER AR7721(ABS94HB,MCG62) FAAR7721100
6
NECK BRACKET AR7722(SECC1.0) ECAR7722000
7
HINGE ASSY AR7717(SK-7,T=22)
ECAR7717000
8
NECK AR7713(ABS94HB.MCG62) FAAR7713100
9
Panel & Chassis M3X0.5+4I-NI MAA00001240
10
Function Board VK-583 LAR577Y 454AAP30001
11
BACK COVER, Neck
& Neck Bracket,
Chassis & Bezel
TPP-4.0+10P-NI MAB20074201
To Next Page
