Acer AL1715

57
D. For AR578 (Acer model:AL1715 b)
No. Photo Part Name Description Part No.
1
Back Cover Screws M4X0.7+6P-ZK MAA20093300
2
BaseASSY(FOOT) AR7714A(ABS94HB,MBK24) FAAR7714A00
3
Stand Screws
M4X0.7+11P-MC
WASHER DIM 8.0
MAA70002400
4
NECK COVER AR7721(ABS94HB,MBK24) FAAR7721000
5
NECK BRACKET AR7722(SECC1.0) ECAR7722000
6
HINGE ASSY AR7717(SK-7,T=22)
ECAR7717000
7
NECK AR7713(ABS94HB.MBK24) FAAR7713000
8
Panel & Chassis M3X0.5+4I-NI MAA00001240
9
Function Board VK-583 LAR578Y 454AAP30011
10
BACK COVER, Neck
& Neck Bracket,
Chassis & Bezel
TPP-4.0+10P-ZK MAB20074202
11
Back Cover AR7812A(PC+ABS,MBK24) FAAR7812A00
