Acer AL1716 - Page 28

DIODES
CKT_ID Component Description Pri
D810 6413060010P00 DIODE_SCHOTTKY_SBF1060CT_10A/60V_TO-220 AB_LITEON 51
D811 6414240014P DIODE_ZNR_MTZJ T_77 24B_T26 51
D811 6414240014PB0 DIODE_ZENER_GDZJ24C_T26_GRANDE 50
ZD101 6414068004PB0 DIODE_ZNR_GDZJ6.8B_T26_GRANDE
ZD801 6414220024P DIODE_ZNR_MTZJ T_77 22D DO_34_T26
ICS
CKT_ID Component Description Pri
I101 6442044900P IC_LINEAR_OZ9936DN_8P_DIP_O2
I301 6444014708P IC_CMOS_AO3401_3P_SOT23_ALPHA&OMEGA 51
I302 6442023326P IC_LINEAR_AIC1084_33PM_3P_TO263_AIC 51
I302 6442023348P IC_LINEAR_AP1084K33LA_3P_TO263_ATC 50
I303 6442043308P IC-LINEAR-AIC1117-18PETR-3P-TO252-AIC IC 51
I303 6442043318P IC_LINEAR_AP1117D18L_3P_TO252_ATC 50
I304 6448018208P IC_CPU_24LC02BT/SN_8PIN_SOIC_MICROCHIP 51
ICS
CKT_ID Component Description Pri
I304 6448018218P IC_CPU_M24C02_WMN6T_8PIN_SO8_ST 50
I306 6447009006P21 IC_ASIC_GM5726H-LF-AB_128P_PQFP_GENESIS DIGITAL
I307 6442045108P IC_LINEAR_STL8110GNL463_3P_SO_23_SENTELI C
I308 6448016508P IC_CPU_24LC16BT/SN_8PIN_SOIC 51
I308 6448016518P IC_CPU_M24C16_WMN6T_8PIN_SO8_ST 50
I309 6448029528P19 IC_CPU_PM25LV020_100SCE_8PIN_SOIC_PMC DIGITAL 51
I309 6448029596P20 IC_CPU_SST25LF020A-33-4C-SAE_8P_SOIC_SST DIGITAL 50
I801 6442048350P05 IC_LINEAR_SG5841JDZ_8_DIP_SG_DIGITAL
I802 6442014000P IC_Linear_LTV_817D_4P_PDIP
I803 6442041005P IC_LINEAR_AP431VLA_3P_TO 92_ANACHIP
Q105 6444023100P IC-CMOS-AOP607-8P-DIP-AOS 51
RESISTORS
CKT_ID Component Description Pri
R101 6212110454P RES. CF_KOHM_100_1/4W_J_T26_MIN
R102 6212110454P RES. CF_KOHM_100_1/4W_J_T26_MIN
R103 6212110354P RES. CF_KOHM_10_1/4W_J_T26_MINI
R104 6224610234P RES. MF_KOHM_102_1/4W_F_T26
R105 6212122054P RES. CF_OHM_22_1/4W_J_T26_MINI
R112 6212110254P RES. CF_KOHM_1_1/4W_J_T26_MINI
R113 6212175454P RES. CF_KOHM_750_1/4W_J_T26_MINI
R118 6212110457P RES. CF_KOHM_100_1/4W_J_T52_MINI
R125 6213230557P RES. CMF_MOHM_3_1/4W_J_T52_KAMAYA:RNV600 V
R126 6224636514P RES. MF_KOHM_3.65_1/4W_F_T26
R130 6224634004P RES. MF_OHM_340_1/4W_F_T26
R131 6212110054P RES. CF_OHM_10_1/4W_J_T26_MINI
R132 6212120254P RES. CF_KOHM_2_1/4W_J_T26_MINI
R133 6212110054P RES. CF_OHM_10_1/4W_J_T26_MINI
R134 6212115254P RES. CF_KOHM_1.5_1/4W_J_T26_MIN
R164 6212110254P RES. CF_KOHM_1_1/4W_J_T26_MINI
R301 6252100156P RES. CHIP_R_KOHM_1_1/10W_J_603
R302 6252100256P RES. CHIP_R_KOHM_10_1/10W_J_603
R304 6252470156P RES. CHIP_R_KOHM_4.7_1/10W_J_603
R305 6252100056P RES. CHIP_R_OHM_100_1/10W_J_603
R307 6252100256P RES. CHIP_R_KOHM_10_1/10W_J_603
R308 6252470256P RES. CHIP_R_KOHM_47_1/10W_J_603
R309 6252240156P00 RES.CHIP-R_KOHM_2.4_1/10W_J_0603
R310 6252680956P RES. CHIP_R_OHM_68_1/10W_J_603
R311 6252100056P RES. CHIP_R_OHM_100_1/10W_J_603
R312 6252680956P RES. CHIP_R_OHM_68_1/10W_J_603
R313 6252750946P RES. CHIP_R_OHM_75_1/10W_F_603
R314 6252750946P RES. CHIP_R_OHM_75_1/10W_F_603
R315 6252750946P RES. CHIP_R_OHM_75_1/10W_F_603
R316 6252100056P RES. CHIP_R_OHM_100_1/10W_J_603
R317 6252680956P RES. CHIP_R_OHM_68_1/10W_J_603
R318 6252100056P RES. CHIP_R_OHM_100_1/10W_J_603
R319 6252100256P RES. CHIP_R_KOHM_10_1/10W_J_603
R320 6252100156P RES. CHIP_R_KOHM_1_1/10W_J_603
R321 6252100056P RES. CHIP_R_OHM_100_1/10W_J_603
5. Spare Parts List (continued)
Go to cover page
27
ACER AL1716W
