Acer AL1716 - Page 29

RESISTORS
CKT_ID Component Description Pri
R322 6252100056P RES. CHIP_R_OHM_100_1/10W_J_603
R323 6252240156P00 RES.CHIP-R_KOHM_2.4_1/10W_J_0603
R324 6252240156P00 RES.CHIP-R_KOHM_2.4_1/10W_J_0603
R325 6252100256P RES. CHIP_R_KOHM_10_1/10W_J_603
R326 6252120256P RES. CHIP_R_KOHM_12_1/10W_J_603
R327 6252120256P RES. CHIP_R_KOHM_12_1/10W_J_603
R328 6252470956P RES. CHIP_R_OHM_47_1/10W_J_603
R329 6252470956P RES. CHIP_R_OHM_47_1/10W_J_603
R330 6252240156P00 RES.CHIP-R_KOHM_2.4_1/10W_J_0603
R348 6252240156P00 RES.CHIP-R_KOHM_2.4_1/10W_J_0603
R349 6252100946P RES. CHIP_R_OHM_10_1/10W_F_603
R350 6252250046P RES. CHIP_R_OHM_250_1/10W_F_603
R351 6252240156P00 RES.CHIP-R_KOHM_2.4_1/10W_J_0603
R356 6252240156P00 RES.CHIP-R_KOHM_2.4_1/10W_J_0603
R357 6252240156P00 RES.CHIP-R_KOHM_2.4_1/10W_J_0603
R358 6252240156P00 RES.CHIP-R_KOHM_2.4_1/10W_J_0603
R359 6252470156P RES. CHIP_R_KOHM_4.7_1/10W_J_603
R360 6252470156P RES. CHIP_R_KOHM_4.7_1/10W_J_603
R362 6252100256P RES. CHIP_R_KOHM_10_1/10W_J_603
R363 6252240156P00 RES.CHIP-R_KOHM_2.4_1/10W_J_0603
R364 6252100256P RES. CHIP_R_KOHM_10_1/10W_J_603
RESISTORS
CKT_ID Component Description Pri
R365 6252100056P RES. CHIP_R_OHM_100_1/10W_J_603
R366 6252100056P RES. CHIP_R_OHM_100_1/10W_J_603
R368 6252820356P RES. CHIP_R_KOHM_820_0.1W_J_TAPING
R369 6252820356P RES. CHIP_R_KOHM_820_0.1W_J_TAPING
R372 6252240156P00 RES.CHIP-R_KOHM_2.4_1/10W_J_0603
R374 6252240156P00 RES.CHIP-R_KOHM_2.4_1/10W_J_0603
R375 6252100056P RES. CHIP_R_OHM_100_1/10W_J_603
R376 6252100056P RES. CHIP_R_OHM_100_1/10W_J_603
R378 6252560246P00 RES.CHIP-R_KOHM_56_1/10W_F_0603_COMPOSTA
R379 6252560246P00 RES.CHIP-R_KOHM_56_1/10W_F_0603_COMPOSTA
R380 6252100056P RES. CHIP_R_OHM_100_1/10W_J_603
R383 6252100056P RES. CHIP_R_OHM_100_1/10W_J_603
R601 6253560242P RES. CHIP_R_KOHM_56_1/8W_F_805
R602 6253150242P00 RES.CHIP-R_KOHM_15_1/8W_F_0805
R603 6253560242P RES. CHIP_R_KOHM_56_1/8W_F_805
R604 6253300242P00 RES.CHIP-R_KOHM_30_1/8W_F_0805
R605 6253150242P00 RES.CHIP-R_KOHM_15_1/8W_F_0805
R801 6228110557P RES. MGF_MOHM_1_1/4W_J_AT52
R802 6201080012P THERMISTOR_OHM_8_3A_P=5_SCK_083_TKS
R804 6228120557P RES. MGF_MOHM_2_1/4W_J_T52
R807 6212133954P RES. CF_OHM_3.3_1/4W_J_T26_MINI
R808 6224630124P RES. MF_KOHM_30.1_1/4W_F_T26
R811 6221239852P RES. MOF_OHM_0.39_2W_J_HOR
R813 6221010157P RES. MOF_OHM_100_1/4W_J_AT52
R814 6221022057P RES. MOF_OHM_22_1/4W_J_AT52
R815 6221022157P RES. MOF_OHM_220_1/4W_J_AT52
R817 6212151354P RES. CF_KOHM_51_1/4W_J_T26_MINI
R823 6212127154P RES. CF_OHM_270_1/4W_J_T26_MINI
R824 6224633024P RES. MF_KOHM_33_1/4W_F_T26
R825 6212110254P RES. CF_KOHM_1_1/4W_J_T26_MINI
R826 6212110254P RES. CF_KOHM_1_1/4W_J_T26_MINI
R827 6224633024P RES. MF_KOHM_33_1/4W_F_T26
R828 6212110254P RES. CF_KOHM_1_1/4W_J_T26_MINI
R851 6224636514P RES. MF_KOHM_3.65_1/4W_F_T26
TRANSISTOR
CKT_ID Component Description Pri
I301 6427000018P50 FET_P-CHNL_AO3419_3P_SOT23_AOS 50
Q101 6426008505P FET_N_CHNL_2N7000TA_200mA/60V_F
Q102 6421000525P TRANSISTOR_NPN_KTC945_P_AT_KEC 50
Q102 6421000535P TRANSISTOR_NPN_2SC945P_TO_92_B/ 51
Q103 6423000215P TRANSISTOR_PNP_KTA733_P_AT_TO 50
Q103 6423000225P TRANSISTOR_PNP_2SA733P_T0_92_B/ 51
5. Spare Parts List (continued)
Go to cover page
28
ACER AL1716W
