3.2 Assembly Procedures
Place OSD PCBA.
Push OSD PCBA
Place LCD module
Insert new AD PCBA
Insert a piece of FFC to AD PCBA
Fasten 4 fixed screws of AD PCBA
Insert 2 pieces of FFC to AD PCBA and Backlight
