Acer AL2216W

7
Table of Contents
Chapter 1 Monitor Features…………………………………….………. 8
1.1 Test Conditions……………………………………….………… 8
1.2 Features…………………….……………………………….…... 8
1.3 LCD Panel Specification……………………………………... 9
Chapter 2 OPERATING INSTRUCTIONS……………….………….……13
2.1 Function Name…………………………………………………13
2.2 OSD Menu Description…..……………………………………15
2.3 OSD Control…..………………………………………………...16
2.4 OSD Menu Screen..……...…………………………………….16
2.5 OSD Function Definition ………………………………………17
2.6 Plug and Play……….……………………………………… . . ..18
2.7 Power Saver……………………………………………………..18
Chapter 3 Machine Disassembly and Assembly……..…….….…19
3.1 Machine Disassembly…………………………………….. .…19
3.2 Machine Assembly……………….…………………………... 23
Chapter 4 Troubleshooting…………………….….…….….……………27
4.1 Abnormal display Troubleshooting……………………….. .27
4.2 Abnormal (On/Off, LCD Display, K/B) Troubleshooting...29
4.3 Abnormal (BIOS, OSD, Other Display) Troubleshooting. .30
4.4 Audio Abnormal………………………….…………………....31
Chapter 5 Connector Information …………...……….………...……32
5.1 Function Block Diagram…………….…………………………32
5.2 Connector Location……..………….…………………………33
5.3 D-sub Mini 15Pin Connector…………………...….…….……33
5.4 DC Connector…………...…………………….…….…….……33
Chapter 6 FRU (Field Replaceable Unit……...……….…………… .34
Chapter 7 Schematic Diagram.……………...……….……………..38
