35
Picture Part name Description Vendor Part
No.
STAND
BASE
Stand Assy,A220Z1-
H02,
40-D009177
LCD
FRONT
BEZEL
Bezel Assy,A220Z1-H02 40-D009188
LCD BACK
COVER
Rear Assy,A220Z1-H02 40-D009181
LCD STAND
NECK
Stand Assy,A220Z1-H02
40-D009177
Hinge Cover Cover Hinge
Assy,A220Z1-H02
40-D009185
Support
Plate
Support Plate,A220Z1-
H02
41-D009178
Cover AD Cover AD Assy,A190A2 41-D008025
