Acer ASPIRE 5251 - Removing the USB Board

Chapter 3 73
Removing the USB Board
1. See “Removing the Upper Cover” on page 61.
2. Unlock the mainboard to USB cable connector.
3. Peel the cable off the adhesive as shown.
4. Remove one (1) screw from the USB board.
Step Size Quantity Screw Type
USB M2*3 1
