Acer ASPIRE 533 - Removing the HDD Module

Chapter 3 53
Removing the HDD Module
1. See “Removing the Lower Cover” on page 51.
2. Remove the one (1) screw.
NOTE: The HDD carrier purchased may differ from the model shown.
3. Move the HDD away from the connector in the direction shown.
Step Size Quantity Screw Type
HDD Module M2*6 1
M2*4 3
