Chapter 3 77
Removing the Power Board
1. See “Removing the Upper Cover” on page 71.
2. Unlock and disconnect the power board FFC.
3. Remove the two (2) screws.
Step Screw Quantity Screw Type
Power Board
Disassembly
T2.5*2Ni 2
