Acer Aspire 5738 Series User Manual

88 Chapter 3
Removing the LCD panel with the Brackets
1. See “Removing the Battery Pack” on page 44.
2. See “Removing the SD Dummy Card” on page 45.
3. See “Removing the DIMM Module” on page 46.
4. See “Removing the Back Cover” on page 47.
5. See “Removing the Hard Disk Drive Module” on page 48.
6. See “Removing the WLAN Modules” on page 51.
7. See “Removing the Optical Drive Module” on page 53.
8. See “Removing the Middle Cover” on page 56.
9. See “Removing the Keyboard” on page 58.
10. See “Removing the LCD Module” on page 59.
11. See “Removing the LCD Bezel” on page 84.
12. See “Removing the Inverter Board (Aspire 5738DG/5738DZG Series only)” on page 86.
13. Disconnect the cable from the web camera.

Acer Aspire 5738 Series Specifications

General

Screen Resolution	1366 x 768
Memory Type	DDR2
Graphics	Intel GMA 4500MHD
Operating System	Windows Vista or Windows 7
Battery	6-cell Lithium Ion
Battery Life	Up to 3 hours
Weight	2.7 kg
Display	15.6 inches
RAM	4 GB
Storage	320 GB HDD
Optical Drive	DVD Super Multi
Chipset	Intel GM45 Express
Wireless	Wi-Fi 802.11b/g/n
Ports	3 x USB 2.0, 1 x HDMI, 1 x VGA, 1 x Ethernet, 1 x Headphone, 1 x Microphone
Processor	Intel Core 2 Duo
