Acer Aspire 5738 Series - LCD Module Disassembly Process; LCD Module Disassembly Flowchart

Chapter 3 83
LCD Module Disassembly Process
LCD Module Disassembly Flowchart
Screw List
Item Screw Color Part No.
B M2.5 x L6 Black 86.00E12.536
C M2 x L3 Silver 86.9A522.3R0
LCD MODULE
LCD BEZEL
Bx4
LCD ASSEMBLY
LEFT LCD
BRACKET
Cx2
RIGHT LCD
BRACKET
Bx1
LCD FPC
CABLE
LCD BACK PANEL
ANTENNAS
LCD MODULE DISASSEMBLY
Bx4
WEB
CAMERA
INVERTER
BOARD*
*(For Aspire 5738DG/
5738DZG only)
