92 Chapter 5
Aspire 5810T/5810TZ/5410T Bottom View
No. Code Connector
1 DM1 DIMM slot 1
2 DM2 DIMM slot 2
3 CN2 Bottom CRT cable connector
4 SSD1 SSD connector
5 BTB1 Miniboard connector
