Acer Aspire 5820T Series - Disassembly Process

Chapter 3 41
Disassembly Process
The disassembly process is divided into the following sections:
• External components disassembly
• Main unit disassembly
• LCD module disassembly
The flowcharts provided in the succeeding disassembly sections illustrate the entire disassembly sequence.
Observe the order of the sequence to avoid damage to any of the hardware components. For example, if you
want to remove the Mainboard, you must first remove the Keyboard, and LCD Module then disassemble the
inside assembly frame in that order.
Main Screw List
Screw Quantity Acer Part Number
M2.5*5 32 86.ARE07.003
M2*3Ni 5 86.A08V7.005
M2.5*4 2 86.PTN07.004
M2.5*4Ni 7 86.EDM07.003
M2.5*3 9 86.PTN07.003
T2.5*2 5 86.B1907.005
M3*3Ni 2 86.N1407.007
M2*3 3 86.ARE07.002
