Acer Aspire 5820T Series - Removing the I;O Board

76 Chapter 3
Removing the I/O Board
1. See “Removing the Upper Cover” on page 63.
2. Unlock and remove the I/O board FFC.
3. Remove the one (1) screw securing the I/O Board to the Lower Cover.
Screw List
Step Screw Quantity Screw Type
I/O Board Disassembly M2.5* 1
