Chapter 1 9
Left View
Right View
# Icon Item Description
1
Kensington lock
slot
Connects to a Kensington-compatible computer security
lock.
Note: Wrap the computer security lock cable around an
immovable object such as a table or handle of a locked
drawer. Insert the lock into the notch and turn the key to
secure the lock. Some keyless models are also available.
2
Ventilation slots Enable the computer to stay cool, even after prolonged
use.
3
External display
(VGA) port
Connects to a display device (e.g., external monitor, LCD
projector).
4
HDMI port Supports high definition digital video connections.
5
USB 2.0 port Connects to USB 2.0 devices (e.g., USB mouse, USB
camera).
6 Line-in jack Accepts audio line-in devices (e.g., audio
CD player, stereo walkman, mp3 player)
Microphone jack Accepts inputs from external microphones.
Headphones/
speaker/line-out
jack with S/PDIF
support.
Connects to audio line-out devices (e.g., speakers,
headphones).
32456
1
213
5
67
4
