Acer Aspire 8935G - Page 102

92 Chapter 3
5. Remove the single screw securing the board to the Upper Cover.
6. Lift and rotate the board in the direction of the arrow to remove it from the Upper Cover.
Step Size Quantity Screw Type
TouchPad Lock
Board
M2*3 1
