Chapter 6 217
LCD Assembly
NOTE: Antennas are not supplied separately. The part number given is for the LCD Module which includes the Antennas.
No. Description Acer P/N No. Description Acer P/N
1 LCD Bezel 60.PD207.001 6 LCD Panel LK.1840D.003
2 LCD Bracket_L 33.PD207.002 7 LCD Bracket_R 33.PD207.001
3 Antenna_L 60.PDA07.003 8 Antenna_R 60.PDA07.003
4 LCD Cable 50.PDA07.002 9 Camera 57.PDA07.001
5 LCD Module 60.PDA07.003
1
2
3
4
5
9
8
7
6
To Next Page
