CONNECT THE SHIELDING AND
BRACKET AS LEFT SHOW.
LOCK UP 4*PCS SCREWS(F3*6) FOR
FIXING SHIELDING.
TRUN OVER LCD.
CHECKING THE BEZEL IF BAD AND
PUT IT TO THE PANEL.
TRUN OVER THE LCD.
