Acer B223W - CE Declaration of Conformity

Acer Acer –LCD-B223W
9
V223W DVI
0 1 2 3 4 5 6 7 8 9 A B C D E F
0
00 FF FF FF FF FF FF 00 04 72 1B 00 00 00 00 00
1
00 00 01 03 80 2F 1E 78 EA DE 95 A3 54 4C 99 26
2
0F 50 54 BF EF 90 A9 40 71 4F 81 40 01 01 95 00
3
95 0F 90 40 01 01 21 39 90 30 62 1A 27 40 68 B0
4
36 00 DA 28 11 00 00 19 00 00 00 FD 00 38 4D 1F
5
54 11 00 0A 20 20 20 20 20 20 00 00 00 FF 00 30
6
30 30 30 30 30 30 30 30 30 30 30 0A 00 00 00 FC
7
00 56 32 32 33 57 0A 20 20 20 20 20 20 20 00 CS
5. Function Specifications
All the tests to verify specifications in this section shall be performed under the following standard conditions
unless otherwise noted. The standard conditions are:
Temperature : 25 ± 5°C
Warm-up time : 30 minutes minimum
Checking display modes : All the specified modes
5.1 Panel general specifications
A General specifications
Supplier
InnoLux
Model name
INL MT190AW01(V-5)
Display Area 410.4 ( H ) x256.5 ( V )
Pixel Pitch 0.285(H) x 0.285(V)
Display Colors: 16.7 Million (6-bit + HI-- FRC)
Number of Pixel 1440x900 pixels
Pixel Arrangement RGB vertical stripe
Brightness 300cd/m
2
(Typ.) 250cd/m
2
(Min.)
Contrast Ratio 700:1 Typical
Viewing Angle
Hor:160°, Ver: 160°
(Typical, CR>10)
Display Mode Normally White
Frame rate 75Hz
Response Time Tr + Tf = 5ms Typical
Surface Treatment
Anti-glare, Haze = 25%,
Hard coating (3H)
Lamp 4 CCFL
Outline Dimension 427.2(W)x277.4(H)x16(D) Typ
5.2 Keypad Function
5.2.1
Control buttons on the front bezel
C
ONTROL KEY KEYS FUNCTION
[AUTO]
A. When OSD un-displays, press [AUTO] to perform auto-adjustment
B. When OSD displays, press [AUTO] to return to previous level menu
C. When “e Color OSD” OSD displays, press [AUTO] to exit the OSD
