Acer Chromebook R753T User Manual

Disassembly Procedures 1-11
Touchpad Module Removal 0
Prerequisite:
Battery Removal
1. Release the latch and disconnect the keyboard FPC from the mainboard connector
(A) (Figure 1-9).
Figure 1-9. Touchpad Module Removal
2. Detach the adhesive tape (B) securing the touchpad FFC to the touchpad module.
Then detach another adhesive tape from the opening on the keyboard compartment
(for keyboard FPC routing) (Figure 1-10).
Figure 1-10. Touchpad Module Removal
A
B
B

Acer Chromebook R753T Specifications

General

Category	Laptop
Operating System	Chrome OS
RAM	4GB
Battery Life	Up to 12 hours
Color	Black
Display Resolution	1366 x 768 pixels
Wireless	802.11ac
Webcam	HD Webcam
