Acer Ferrari One 200 Service Guide

Chapter 4 137
USB Failure (Right up/down side)
If the rightside USB port fails, perform the following actions one at a time to correct the problem. Do not
replace non-defective FRUs:
Other Failures
If the VGA board, LAN Port, external MIC or Speakers, PCI Express Card, 5-in-1 Card Reader or Volume
Wheel fail, perform the following general steps to correct the problem. Do not replace non-defective FRUs:
1. Check whether the drive is OK.
2. Verify that the Test Fixture is ok.
3. Swap the mainboard and retest.
Start
Check USB/B to
M/B cable
Re-assemble the
USB/B cable to M/B
OK
NG
Check USB/B
OK
Swap USB/B and
USB cable
OK
NG
Swap M/B
Start
Check USB/B to
M/B cable
Re-assemble the
USB/B cable to M/B
OK
NG
Check USB/B
OK
Swap USB/B and
USB cable
OK
NG
Swap M/B

Acer Ferrari One 200 Specifications

General

Processor family	AMD Athlon
Processor frequency	1.2 GHz
Processor manufacturer	AMD
Internal memory	3 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	4 GB
HDD speed	5400 RPM
HDD capacity	320 GB
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Compatible memory cards	MMC, MS PRO, SD, xD
Display diagonal	11.6 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Display number of colors	16.78 million colors
Bluetooth version	2.1+EDR
Networking features	Gigabit Ethernet, WLAN
Mobile network generation	3G
Graphics card	Radeon HD 3200
Audio system	HD Audio
Number of built-in speakers	2
Operating system installed	Windows 7 Home Premium
Cable lock slot type	Kensington
Product type	Netbook
Product color	Red
Charging port type	DC-in jack
USB 2.0 ports quantity	3
Battery capacity	5600 mAh
Battery life (max)	4 h
Number of battery cells	6
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V

Weight and Dimensions

Depth	204 mm
Width	285 mm
Weight	1500 g
Height (rear)	30 mm
Height (front)	24 mm
