32 Chapter 2

DOS Flash Utility

Perform the following steps to use the DOS Flash Utility:

1. Press F2 during boot to enter the Setup Menu.

2. Select Boot Menu to modify the boot priority order, for example, if using USB HDD to Update BIOS, move

USB HDD to position 1.

3. Execute the FLASH.BAT batch file to update BIOS.

The flash process begins as shown.

4. In flash BIOS, the message Please do not remove AC Power Source displays.

NOTE: If the AC power is not connected, the following message displays.

Plug in the AC power to continue.

5. Flash is complete when the message Flash programming complete displays.

Item Specific Help

ESC

Help

Exit

Select Item

Select Menu

Change Values

Select SubMenu

Enter

F10

Setup Default

Save and Exit

Boot priority order:

1: IDE0 : WDC WD2500BEVT-22ZCT0

Boot priority order:

1. IDE0 : WDC WD2500BEVT-22ZCT0

2: CD/DVD:

3: PCI LAN: Atheros Boot Agent

4: USB HDD:

5: USB FDD:

USB KEY:

USB CD/DVD:

F5/F6

Phoenix SecureCore (tm) Setup Utility

Main Boot ExitSecurityInformation

Keys used to view or

configure devices:

Up and Down arrows

select a device.

<F6> and <F5> moves

the device up or down.

Other manuals for Acer Ferrari One 200

Quick Guide12 pages

Questions and Answers:

M
martinethanJul 25, 2025
What to do if my Acer Ferrari One 200 Laptop has no POST or video?
- M
  Matthew GomezJul 25, 2025
  If your Acer Laptop shows no POST or video, first ensure the internal display is selected and that the computer has power by checking if the fans start or status LEDs light up. Drain any stored power by removing the power cable and battery, then hold the power button for 10 seconds. Connect an external monitor to the computer. Disconnect power and all external devices, including port replicators or docking stations. Reseat the memory modules and remove the drives.

Acer Ferrari One 200 Specifications

General

Processor family	AMD Athlon
Processor frequency	1.2 GHz
Processor manufacturer	AMD
Internal memory	3 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	4 GB
HDD speed	5400 RPM
HDD capacity	320 GB
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Compatible memory cards	MMC, MS PRO, SD, xD
Display diagonal	11.6 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Display number of colors	16.78 million colors
Bluetooth version	2.1+EDR
Networking features	Gigabit Ethernet, WLAN
Mobile network generation	3G
Graphics card	Radeon HD 3200
Audio system	HD Audio
Number of built-in speakers	2
Operating system installed	Windows 7 Home Premium
Cable lock slot type	Kensington
Product type	Netbook
Product color	Red
Charging port type	DC-in jack
USB 2.0 ports quantity	3
Battery capacity	5600 mAh
Battery life (max)	4 h
Number of battery cells	6
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
