Acer H243 - 05 Spare Parts List; Spare Parts List

Acer Acer –LCD-H243H
45
05 Spare parts List
82424171A120R
OEM PART NO DESCRIPTION MOQ N/A
792381300701R PCBA,I/F BOARD(EMEA,W/SPK),LP2441-717 RO 50 1
792381400700R PCBA,P/I BOARD,W/SPK,LP2441-717 ROHS 50 1
792381500000R PCBA,POWER KYEPAD/B,LP2441 ROHS 50 1
792381500010R PCBA,TOUCHPAD BOARD,LP2441 ROHS 50 1
453070801190R PWRCORD 16A/250V BLK 6FT VDE/KTL H05VV-F 50 1
453030300370R CABLE,DVI-D 18+1P MALE 6FT BLACK , ROHS 50 1
453030300371R CABLE,DVI-D 18+1P MALE 6FT BLACK 50 1
453010100380R CABLE,D-SUB 15P MALE 6FT BLACK/BLUE, ROH 50 1
453030300120R
CABLE AUDIO 1P 6FT BLACK/GREEN
CP03B06P0
50 1
430303002230R HRN LVDS FFC 30P 166.5mm W/TASTE 50 1
430300400390R HRN ASS'Y 4P 27MM UL1571#28 50 1
430300802060R HRN ASSY, 2X4P TO 1X8P ,220mm,UL1571#28 50 1
714050021200R ASSY BACK COVER,LP2441 50 1
714030022100R ASSY BEZEL ,LP2441 50 1
714011206200R ASSY STAND ,LP2441 50 1
714020018200R ASSY BASE,LP2441 50 1
501020228602R COVER,BACK,LP2441 50 1
502060201100R HINGE,LP2441 50 1
501260210800R STAND, LP2441 50 1
502090103100R CHASSIS,W /HDMI, W/DVI,LP2441 50 1
631102240130R LCP 24" M240HW01-V0-00(A)(AUO)ROHS 50 1
