37
English
L811/EL8630Ua/HL-4K30Ua/GL825Ua/VL-730Ua/L812/EL8632Ua/
HL-4K32Ua/GL827Ua/VL-732Ua/L811+
* Design and specifications are subject to change without notice.
Resolution Native: 3840x 2160
Maximum: UHD (3,840 x 2,160)
Aspect ratio Auto, 4:3, 16:9, Full, L.Box
Projection lens F = 2, f = 24.85 mm,
1:1.0 Motorized Focus
Projection screen size (diagonal) 70" – 120" (1.78 m – 3.05 m)
Projection distance with clear
focus
0.059 m – 0.312 m (2.32" – 12.28")
Throw ratio 0.252 (100”@0.549 m)
Horizontal scan rate 15 – 100 KHz
Vertical refresh scan rate 24 – 120 Hz
Keystone correction +/-5 Degrees (Vertical & Horizontal), Manual
Audio 10W speaker x 2
Power consumption Standard mode: 370 W @100 VAC
ECO mode: 220 W @ 100 VAC
Standby mode: < 0.5 W
Power socket V
USB V
LAN V
USB Type C V
HDMI 1 V
HDMI 2 V
USB (for service) V
DC 12V OUT V
S/PDIF V
RS232 V
AUDIO OUT V
WIRELESS DONGLE V
I/O connectors
L811/EL8630Ua/HL-4K30Ua/GL825Ua/VL-730Ua/L812/
EL8632Ua/HL-4K32Ua/GL827Ua/VL-732Ua/L811+
