3 Assemble Keypad Board:
(1) Assemble all the keypad
components.
(2) Plug in 1 FPCU and screw
4 screw to assemble the
Keypad Board.
4 Plug in 1 IR Receiver wire and
1 FPC connector; then, screw
6 screws in the Bottom Cover
to assemble the Top Cover
Module.
